硬度标尺 | HRC、HB、HV、HRA、HRB、HSD、σ、HL | |
测量精度* | -布氏硬度标尺(HB) | 10 |
-洛氏硬度标尺(HRC) | 1.5 | |
-维氏硬度标尺(HV) | 12 | |
-肖氏硬度标尺(HSD) | 2 | |
-抗拉强度σ,最大% | 5 | |
计算平均值的测量次数 | 最多99次 | |
可存储校准曲线的数量 | 最多1000个(可分组) | |
电源:锂离子可充电电池 | 3.7-4.2V,1500-1700mAh | |
连续工作时间 | 至少12小时 | |
工作温度范围 | -30 —— +40℃ | |
外形尺寸 | 125×55×20mm | |
主机重量 | 120g |
*测量精度通过硬度标准块确定,在至少10次测量中取平均值。
材料、硬度标尺、测量范围:
材料 |
标尺 | 硬度测量范围 | |||||
里氏 | 超声波 | 便携式洛氏 | |||||
D、DC | DL | G | C |
U-10N U-50N U-100N | SPR | ||
钢、低合金钢、铸钢 | HL | 0-1000 | 0-1000 | 0-1000 | 0-1000 | ||
HB | 75-654 | 81-646 | 90-646 | 81-694 | 75-654 | 75-450 | |
HV | 75-1000 | 80-950 | 81-1012 | 75-1000 | 75-1000 | ||
HRC | 20-70 | 21-67 | 20-70 | 20-70 | 20-70 | ||
HRA | 60-93 | 60-93 | |||||
HRB | 25-100 | 37-100 | 48-100 | 25-100 | |||
HSD | 20-100 | 31-97 | 30-102 | 20-100 | |||
σ、MPA | 370-1740 | 370-1740 | 370-1740 | 370-1740 | 370-1740 | ||
工具钢 | HL | 0-1000 | 0-1000 | 0-1000 | 0-1000 | ||
HV | 80-900 | 80-905 | 98-942 | ||||
HRC | 20-70 | 21-67 | 20-67 | ||||
不锈钢 | HL | 0-1000 | 0-1000 | 0-1000 | 0-1000 | ||
HB | 85-655 | ||||||
HV | 85-802 | ||||||
HRC | 20-62 | ||||||
灰铸铁 | HL | 0-1000 | 0-1000 | 0-1000 | 0-1000 | ||
HB | 90-664 | 92-326 | |||||
球墨铸铁 | HL | 0-1000 | 0-1000 | 0-1000 | 0-1000 | ||
HB | 95-686 | 127-364 | |||||
铝合金 | HL | 0-1000 | 0-1000 | 0-1000 | 0-1000 | ||
HB | 19-165 | 20-187 | 19-168 | 21-167 | 19-165 | 75-450 | |
HV | 75-1000 | ||||||
HRB | 24-85 | 24-85 | 28-86 | 23-85 | 24-85 | ||
黄铜(铜锌合金) | HL | 0-1000 | 0-1000 | 0-1000 | 0-1000 | ||
HB | 40-173 | 40-173 | 75-450 | ||||
HV | 75-1000 | ||||||
HRB | 14-195 | ||||||
青铜(铜铝/铜锡合金) | HL | 0-1000 | 0-1000 | 0-1000 | 0-1000 | ||
HB | 60-300 | 60-300 | 75-450 | ||||
HV | 75-1000 | ||||||
锻铜合金 | HL | 0-1000 | 0-1000 | 0-1000 | 0-1000 | ||
HB | 45-315 | 75-450 | |||||
HV | 75-1000 |
1、带探头的仪器主机(探头数量和型号由客户选择);
2、充电器、mini-USB-USB A型数据线缆(用于连接计算机);
3、软件光盘(用于传输数据至计算机并处理测量结果);
4、使用说明书(中英文各一份);
5、防震仪器箱。
适用范围及主要技术参数:
探头类型 | D型 | C型 | DL型 | G型 |
适用范围 | 通用标准探头,适用于大多数场合的硬度测量任务。 | 适用于测量对压痕尺寸要求较小的工件,具有表面硬化层和电镀层的零部件,也适用于薄壁零件和对冲击敏感产品的硬度测量。 | 适用于在难以接触位置、狭窄空间或内孔表面的硬度测量。 | 适用于检测表面粗糙度较大的大型零部件,例如锻造或铸造零件,或表面粗糙的粗晶材料(铸铁)工件。 |
被测试样最小厚度 | 10mm | 5mm | 10mm | 70mm |
最大表面粗糙度Ra,μm | 3.2 | 1.6 | 3.2 | 12.5 |
探头外形尺寸 | φ23×139mm | φ23×139mm | φ23×255mm | φ32×248mm |
